操作穩定土拌和機需要牢記5大要點
來源：http://m.xintangt.com/ 日期：2023-02-02
操作穩定土拌和機注意事項：
Precautions for operation of stabilized soil mixer:
開機前：做好各項檢查為開機做好準備。
Before startup: check all items to prepare for startup.
1、檢查各螺栓是否緊固，尤其是攪拌機內攪拌葉片及各料倉振動器葉片。
1. Check whether all bolts are fastened, especially the mixing blades in the mixer and the blades of each silo vibrator.
2、檢查皮帶托輥是否有缺少的地方，各轉動位置是否潤滑充分。攪拌機各軸承每工作四小時打黃油一次，其余地方工作三天至一星期打一次。
2. Check whether the belt idler is missing and whether each rotating position is fully lubricated. Each bearing of the mixer shall be buttered once every four hours, and the rest shall be buttered once every three days to a week.
3、電纜電線是否有漏電破損的地方，一般機器每工作一星期就要停機檢查一下穩定土拌和機各電器件螺絲是否緊固，線纜是否破損。各電氣及控制柜要牢固接地?？偟鼐€一般深度至少1.5米至2米。變頻器建議單獨接地。接地時可以在地線處澆灌鹽水增強接地效果。
3. If there is any leakage or damage in the cable and wire, generally the machine should be stopped every week to check whether the screws of the electrical parts of the stabilized soil mixer are tight and whether the cable is damaged. All electrical and control cabinets shall be firmly grounded. The general depth of the ground wire shall be at least 1.5 meters to 2 meters. The frequency converter is recommended to be grounded separately. When grounding, salt water can be poured at the ground wire to enhance the grounding effect.
4、看各給料皮帶是否跑偏。給料倉料門是否卡死，水泥罐閥門是否開啟，若關閉則在穩定土拌和機開機前打開。一般水泥倉料門一邊至少開20公分（20cm），即水泥料門開四十公分大。
4. Check whether each feeding belt is deviated. Check whether the material door of the feed bin is blocked, and whether the valve of the cement tank is open. If it is closed, open it before the start of the stabilized soil mixer. Generally, one side of the cement silo door shall be at least 20 cm (20 cm) open, that is, the cement door shall be 40 cm wide open.
5、檢查料是否充足，水是否暢通。如有氣路，檢查空壓機是否工作正常，穩定土拌和機放料門是否開關流暢。
5. Check whether the material is sufficient and the water is unblocked. If there is an air path, check whether the air compressor works normally and whether the discharge door of the stabilized soil mixer is opened and closed smoothly.
穩定土拌和機的結構特點：
Structural characteristics of stabilized soil mixer:
1、發動機：采用康明斯發動機。結構緊湊、噪聲小、易于維修、廢氣排放低等優點。
1. Engine: Cummins engine is adopted. It has the advantages of compact structure, low noise, easy maintenance and low exhaust emission.
2、液壓系統：行走采用變量泵與定量馬達組成的閉式系統。工作裝置采用變量泵與定量馬達組成的閉式系統。傳動效率高、噪聲低，可實現功率自動分配。結構簡單、維修方便。
2. Hydraulic system: a closed system composed of variable displacement pump and quantitative motor is used for walking. The working device adopts a closed system composed of variable displacement pump and quantitative motor. With high transmission efficiency and low noise, automatic power distribution can be realized. Simple structure and convenient maintenance.
3、液壓件：液壓泵、液壓馬達采用進口元件。效率高、性能穩定、使用壽命長。
3. Hydraulic parts: hydraulic pump and hydraulic motor adopt imported components. High efficiency, stable performance and long service life.
4、變速箱與驅動橋。采用兩速變速箱，低速用于作業和爬坡，高速用于行駛。驅動橋采用剛性驅動橋。結構緊湊、質量可靠。
4. Transmission and drive axle. Two-speed transmission is adopted, low speed is used for operation and climbing, and high speed is used for driving. The drive axle is rigid. Compact structure and reliable quality.
5、駕駛室全封閉駕駛室。寬敞明亮、視野開闊、密閉性好，司機耳邊噪聲低。可另配空調。
5. The cab is totally enclosed. Spacious and bright, wide vision, good airtightness, low noise in the driver's ear. It can also be equipped with air conditioner.
6、操縱系統：人性化設計、較大限度降低駕駛疲勞。操縱輕便、靈活、可靠。
6. Control system: humanized design, greatly reducing driving fatigue. The operation is light, flexible and reliable.
